    High Brightness 12.1 inch AA121SK02 tft lcd panel with 246×184.5 mm Active Area

    Ask Lasest Price
    Brand Name : Mitsubishi
    Model Number : AA121SK02
    Certification : ISO9001
    Payment Terms : T/T, Western Union, MoneyGram, T/T
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    High Brightness 12.1 inch AA121SK02 tft lcd panel with 246×184.5 mm Active Area

    Normally White 12.1 inch AA121SK02 TFT LCD Module Mitsubishi with 246×184.5 mm Active Area


    Here comes our other LCD panels stock for your easy reference:

    Panel ModelBrandSizeResolution
    AA150XN21Mitsubishi15.0"1024×768
    AA121TD03Mitsubishi12.1"1280×800
    AA150XT11-DE-01Mitsubishi15.0"1024×768
    AA084SD11-DA-01Mitsubishi8.4"800×600

    Pls contact to us for more stock information: salespm@nselectronic.com.hk


    AA121SK02 Information


    Panel Size :12.1 inch
    Dot Resolution :800(RGB)×600 (SVGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :82 PPI
    Aspect Ratio :4:3 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.1025×0.3075 mm (H×V)
    Pixel Pitch :0.3075×0.3075 mm (H×V)
    Weight :760g (Typ.)
    Active Area :246×184.5 mm (H×V)
    Bezel Area :249.0×187.5 mm (H×V)
    Outline Dimension :280×210 mm (H×V)
    Outline Depth :12.0 (Typ.) mm
    Holes & Brackets :Face mounting holes (4-Φ3.5, 2-R1.75) on left bezel, right slugs
    Landscape or Portrait :Landscape type
    Touch Panel :Without
    isplay Mode :TN, Normally White, Transmissive
    Brightness :300 cd/m² (Typ.)
    Contrast Ratio :200 : 1 (Typ.) (Transmissive)
    Display Color :262K (6-bit)
    Response Time :20/30 (Typ.)(Tr/Td)
    Viewing Angle :60/60/40/50 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction :6 o'clock
    White color Chromaticity :Wx:0.350; Wy:0.380
    Sunlight Readable :N

    FAQ

    1.Payment
    What are the terms of payments you offer?
    Payment of the goods should be sent in USD or RMB on the basis of goods Values. We accept payment of T/T, Western Union, Money Gram, PayPal and cash only
    2.Shipment
    How long will it take to deliver goods?
    We will deliver the goods within 3-5 days for spare parts, other goods maybe take a little more times to test and prepare, we will deliver the goods within the deadline which both parties agreed.
    What kind of packaging you offer?
    We will pack the goods well with exporting packages to make sure all goods in a good condition during storage and delivery.
    What kind of transportation methods you offer?
    A.We always use express delivery like DHL, UPS, FedEx, TNT and EMS, as we enjoy perfect discount in these companies. But if buyers provide us accounts of their own, transportation fee paid by such accounts are also welcomed.
    B.We also always transport by air and sea for the goods with large quantity, and we will confirm freight with buyers' prior delivery.
    How about the insurance during transportation? How to deal with the responsibility?
    Buyers should take the full responsibility for shortage of goods if the goods are checked by any custom during transportation. During transportation, if goods are missed because of having been detained by custom in China, all loss thus occurred should be borne by us; if missing or detained of goods are occurred in other country except China, all loss should be borne by buyers
    What Locations can you ship to?
    We can send the goods to the whole world if the express way can deliver it.
    3.Goods Return
    What conditions should be considered to return goods?
    A.Goods were delivered by SR
    B.Goods are within our warranty policy
    How long will you take to deal with the returned goods?
    We will provide the first feedback within 5 working days.
    4.Others
    What kind of problem will happen usually?
    Some goods will be out of stock and cannot offer, because it cannot meet the quality request or really out of stock. Anyway we will contact the client to confirm well before shipping.


    Guarantee:

    (1) All items will be strictly tested and shipped with safe & professional package.

    (2) We have 12 months warranty for each LCD screen panel, depend on the different LCD panel models.

    (3) We will do our best to solve any possible problems for your after sale sevice. Please contact with us if any problems.
