Normally White NL8060BC21-06 8.4 inch, 800×600 Outline 200×152×11 mm Frequency 60Hz

N&S ELECTRONIC CO., LIMITED
Contact Now
    Buy cheap Normally White NL8060BC21-06 8.4 inch, 800×600 Outline 200×152×11 mm Frequency 60Hz from wholesalers

    Buy cheap Normally White NL8060BC21-06 8.4 inch, 800×600 Outline 200×152×11 mm Frequency 60Hz from wholesalers
    • Buy cheap Normally White NL8060BC21-06 8.4 inch, 800×600 Outline 200×152×11 mm Frequency 60Hz from wholesalers
    • Buy cheap Normally White NL8060BC21-06 8.4 inch, 800×600 Outline 200×152×11 mm Frequency 60Hz from wholesalers

    Normally White NL8060BC21-06 8.4 inch, 800×600 Outline 200×152×11 mm Frequency 60Hz

    Ask Lasest Price
    Brand Name : NLT
    Model Number : NL8060BC21-06
    Certification : ISO9001
    Payment Terms : Western Union, T/T, MoneyGram, T/T
    Supply Ability : 500PCS/DAY
    Delivery Time : 1-3 Working Days
    • Product Details
    • Company Profile

    Normally White NL8060BC21-06 8.4 inch, 800×600 Outline 200×152×11 mm Frequency 60Hz

    Normally White NL8060BC21-06 8.4 inch, 800×600 Outline 200×152×11 mm Frequency 60Hz​

    Packaging & Delivery
    Packaging Details: Safe & Professional packing or as requirement for the LCD Screen replacements.
    Delivery Detail: 2-3 days after receipt of payment
    Payment terms: We accept T/T, PayPal, Western Union and others.

    NL8060BC21-06 Basic Information

    Panel ModelNL8060BC21-06
    Panel BrandNEC
    Descritiona-Si TFT-LCD ,8.4 inch, 800×600
    Panel Typea-Si TFT-LCD
    Operating Temperature-20 ~ 70 °C
    Storage Temperature-30 ~ 80 °C
    Vibration Resistance2.0G (19.6 m/s²)

    NL8060BC21-06 Optical Features

    Display ModeTN, Normally White, Transmissive
    Brightness650 cd/m² (Typ.)
    Contrast Ratio600 : 1 (Typ.) (Transmissive)
    Display Color262K/16.7M (6-bit / 6-bit + Hi-FRC)
    Color Gamut40% NTSC (CIE1931)
    Response Time6/19 (Typ.)(Tr/Td)
    Viewing Angle80/80/80/60 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction6 o'clock
    White color ChromaticityWx:0.313; Wy:0.329
    White Variation1.25/1.40 (Typ./Max.)(5 points)
    Sunlight ReadableN

    NL8060BC21-06 Electronics Feature

    Vertical Frequency60Hz
    Reverse ScanYes (180°)
    Total Power Consumption5.5W (Typ.)

    FAQ
    1. Q: Where can I get the price?
    A:We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.
    2. Q: How can I get a sample to check your quality?
    A: After price confirmation, you can require for samples to check our quality.
    3. Q: What about the lead time for mass production?
    A: It depends on your order quantity and the season you place the order.
    4. Q: What are your terms of payment?
    A: We accept T/T, Western Union, MoneyGram, PayPal.

    Below are our other LCD panels stock for your easy reference:
    Panel ModelBrandSizeResolution
    H426TAN02.0AUO4.3"720×1280
    LC490EQJ-SGK1LG Display49"3840×2160
    LC420EQJ-SGE2LG Display42"3840×2160
    LC650EQK-FGK5LG Display65"3840×2160
    CLAG080WQ05 AXCPT8.0"800×1280
    TT070WSQ-N10BOE7.0"1024×600
    C097SNX1 R1IVO9.7"1024×768
    C097SNX1 R0IVO9.7"1024×768
    P062SWP1 R1IVO6.2"800×480
    P101NWT4 R0IVO10.1"1024×600
    HSD055FMW1-D00HannStar5.5"540×960
